Item HYT480
Engine Model /Name Gasoline Engine
Rated Power kw 7.2
Max Power kw 8.6
Rotating Speed Rate Rotating Speed 3600
Rate Speed of Power Output Shaft 3600
Displacements ml 420
Ignition Mode Compression Ignition
Start Mode Manual
Fuel Tank Capacity 1 5.5
Engine Oil Capacity 1 1.1
Power Tiller "Machine's Dimension
(Lengthxwidthxheight) " mm 1635x1500x810
Machine's Weight kg 130
Transmission mode Full gear Transmission
Connection Mode Direct Connection
Speed Runnning Speed Fast km/h 10
Runnning Speed Slow km/h 5
Blades Rotate Speed r/min 61
Max. radius of gyration mm 180
Total Blades Quantity pcs 40
Total Groups of Blades pcs 10
Blades for Each group pcs 5x4+4x1
Distance Between 2 neighbouring faces are mm 135
Diameter of the farming Blades cm 36
Rotary Blade Type Bent Blade for Dry Land
Clutch Mode Wet Multiple Disc Clucth Land Manual Control
Tilling Depth cm >10
Tilling Width cm Max 150
Working Efficiency h m/h >0.04
Consumption Fuel kg/h m <1.50
Gear-Box's Oil capacity L 2.4
